SMD LED 3030 RGB Chip 0.5W 1.5W Tunable 3 In 1 Excellent Color Blending Led Chips
SMD LED 3030 RGB Chip 0.5W 1.5W Tunable 3 In 1 Led Chips
- 3 in 1 3030 RGB SMD LED with Good color consistency
- 0.5W version and 1.5W Version 3030 RGB SMD LED Chip are available
- Low power consumption, cost effective
- Package Size:3.0(L)x3.0(W)x0.6(H)mm
- 99.99% gold wire welding
Application
- Buliding/Outdoor lighting
- Downlight, Wall lamp, Garden lighting
- Stage lighting, Strip light, Signal light
- Spot lighting, Ceiling lighting
- Decorative Lighting, Lighting Engineering
- Other illuminations
Specifications
|
Models
|
HY-3030RGBL30-3S-0.5W
|
HY-3030RGBL65-3S-1.5W |
| Electronic power |
0.5W |
1.5W |
| Wavelength |
Red: 620-630nm Blue: 460-470nm Green: 520-530nm |
Red: 620-630nm Blue: 460-470nm Green: 520-530nm |
| VF |
3.0-3.4V |
3.0-3.4V |
| IF |
60mA*3 |
150mA*3 |
| Lumen |
R:8-10LM G:15-20LM B:4-5LM |
R:20-25LM G:35-45LM B:10-14LM |
| Bracket types |
PCT |
EMC |
| WHOLE SIZE |
3.0*3.0mm |
3.0*3.0mm |
| CHIP |
Sanan/Epistar/Epileds |
Epileds/Sanan/Epistar |
| View angle |
120° |
120° |
| Warranty |
3years |
3years |
| Leading time |
7-15Days |
7-15Days |
Electrical - Optical Characteristics at Ta=25℃
Absolute Maximum Ratings at Ta=25℃
Optica Characteristic curve
Product Dimmensions(Tolerance:+/-0.1, Unit:mm)
Packaging Specifications
- The LEDs are packed in cardboard boxes after taping
- Carrier Tape Dimensions(Uns:mm)
FAQ
Q1.Do you offer a guarantee for your products?
A: Yes, we provide a 3 year warranty on our products.
Q2. Can I place a sample order for an led light?
A: Yes, we welcome sample order to test and check the quality. Mixed samples are okay.
Q3. How to place an order for led light?
A: Firstly let us know your requirements or application. Secondly We will provide a quote according to your requirements or our suggestions.Thirdly the customer confirms the samples and places an order.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 2-5 days to arrive. Airline and sea shipping also optional.depending on the option chosen by the customer.
Q5. What is the lead time for your products?
A: The lead time for a sample order is 1-3 days, and it takes 7-15 days for mass production depending on the order quantity.
Q6. Do you have a minimum order quantity (MOQ) for LED light orders? How do you pay for them?
A: The MOQ for each model is 100pcs. We accept T/T, Paypal, and Western Union as payment methods.
Q7. How do you handle faulty products?
A : Our products are produced under strict quality control system, and the defective rate is less than 0.2%. During the guarantee period, we will send new products to the customer.
