Detail Information

Model:	HY-5054W60-650-6W	Voltage（V）:	9V
Current(mA):	300-600	CRI（Ra）:	80
Color Temperature:	6000-6500K	Luminous（lm）:	650-700lm
Color:	White	Substract:	EMC
High Light:	9V LED CHIP 5050 , 9V LED CHIP 6000K , High Power SMD LED Chip

Product Description

3W Led 5050 SMD Chip White 6000-6500K Good Market High Power Smd Led

5050/5054 SMD Chip LED 1W White 6000-6500K

HuanYu 5050 SMD LED 1W 2W 3W 4W 5W Round LES has color temperature from 2600K to 7000K, as well as excellent color reproduction with CRl min. 70, 80 and 90. With standard forward current, 5050 smd led with high watts maximum 5W, becomes more and more popular in many high-end lighting manufacturer

Features

Compact pacakage size at 5.0mm*5.4mm
Excellent color Reproduction
Different voltage 3V, 6V,9V,12V,24V36V etc
Super High luminous efficiency 200-220lm/w
RoHS Complaint
Big scale of producing makes sure that your purchase cost is lower but with higher quality.
Advanced production line guarantees stable quality and longer life span.

Spec

Models	HY-5054W60-650-3W
Electronic power	3W
Current(IF)	600mA
VF	9.0-9.2V
Lminous	650-700lm
CRI	80
Color temperature	6000-6500K
CHIP	Sanan/Epistar
VIEW ANGLE	120°
Warranty	3 years

9V LED CHIP 5050 6000K-6500K 6W High Power SMD LED Chip 0

Application

Also Widely applied in Led High Bay light ; Led Street light ; Stadim light; Led Studio light; Commercial lighting , indoor lighting and other lighting area

FAQ

Q:Are you a factory or a trade company?
A: Yes, We are the manufacturer specialize in SMD and COB led chips since 2013.

QHow to process the order?

A: 1. Let us know the requirements(size, color, power and quantity) of the products you need.
2. We will send you the quotation and check the stock.
3. We will send you proformer invoice after you confirm the samples.
4. You make the payment after checking the details.
5. We will arrange the delivery and continue to provide you the best service.

Q: Can I get some samples for tests?
A: Yes, we can offer free samples, so you can have an intuitive understanding about our LED quality and performance. But our clients should pay for the shipping freight themselves.

Q: What about the lead time?
A: Generally, it will take 3-5 working days for sample and 7-20 working days for mass order.

Q: How many years of warranty of products you offer? And how do you deal with the LED working issues?
A: We offer 3-year warranty by default, and longer warranty can be negotiated. If there is any problem with the product during the warranty, please feel free to contact us.

Q: Do you accept customized products?
A: Yes, we can offer OEM and ODM service as per your request. Please kindly leave us messages about your requirements, our sales engineer will check the details as soon as possible.

Tag:

Place of Origin:	China
Brand Name:	HuanYu Dream
Certification:	Rohs
Model Number:	HY-5054W60-650-6W

Minimum Order Quantity:	Negotiable
Price:	Negotiable
Packaging Details:	1000pcs/Reel
Delivery Time:	7-9 Work Days
Payment Terms:	T/T, Paypal,Ali Pay
Supply Ability:	200KKpcs/Month
