0.06W 3V 3528 SMD LED Chip 520nm-525nm Green LED Chip Wide Viewing Angle

Basic Information
Place of Origin: China
Brand Name: HuanYu Dream
Certification: RoHS
Model Number: HY-3528 Green
Minimum Order Quantity: 2000pcs
Price: Negotiable
Packaging Details: 2000pcs/Roll
Delivery Time: 7-9 Work Days
Payment Terms: T/T, Paypal,Ali Pay
Supply Ability: 500kpcs/Day
Detail Information
Types: 3528 Smd Led Chip Green Colors Wavelength: 520-525nm
Voltage: 3.0-3.2V IF: 20mA
Lumens: 7-9lm Chip Material: InGaN
High Light:

3528 Smd Led Chip

,

SMD LED Chip 520nm

,

525nm Green LED Chip


Product Description

3528 Smd Led Chip Green Colors 520-525nm Features



1. Package Size:3.5(L)x2.8(W)*1.8(H)mm

​2.  P-LCC-2 package.

3. ​Copper base with ultra stability

4.Wide colors: Red; Green; Blue; UV; Orange; Yellow; Amber.. Also provide 3528RG
5. Optical indicator.
6. Colorless clear window.
7. Ideal for backlight and light pipe application.
8. Inter reflector.
9. Wide viewing angle.

10. Suitable for automatic placement equipment.

11. Super long lifetime:50000hrs









3528 SMD LED Chip is the price/performance leader for commercial indoor slutions compare to the cost and efficiency. Typical PLCC-2 type white smd led, Compact SMD design with high brightnes,Consistent Color and Smooth environment, Widely apply in Decorative lighting, Light Strip,Commercial Illuminate and displays: Advertising words, light box; Garden lighting; Led back lighting; and fit for different working environment








Specifications



Electronic power 0.06W
Color  Green (520-525nm)
VF 3.0-3.2V
IF 20mA
Chip Brand Sanan
LUMINUOUS EFF 7-9lm
Chip size(mil) 8*15mil





Absolute Maximum Ratings (TA=25ºC)



Item Symbol Absolute Maximum Rating Unit
Forward Current IF 20 mA
Pulse Forward Current IFP 50 mA
Reverse Voltage VR 5 V
Power Dissipation PD 100 mW
Operating Temperature Topr -40ºC To +85ºC °C
Storage Temperature Tstg -40ºC To +85ºC °C
Soldering Temperature Tsld

Reflow Soldering: 260ºC

Hand Soldering : 350ºC

for 10sec.

for 3sec.



Product Dimension(Tolerance:+/-0.1mm. Unit:mm)

0.06W 3V 3528 SMD LED Chip 520nm-525nm Green LED Chip Wide Viewing Angle 0







Packaging(Units:mm)



Taping Specifications

0.06W 3V 3528 SMD LED Chip 520nm-525nm Green LED Chip Wide Viewing Angle 1





Reel Dimension



0.06W 3V 3528 SMD LED Chip 520nm-525nm Green LED Chip Wide Viewing Angle 2











3528 Smd Led Chip Application

  • High Power LED Lamp
  • Indoor lighting: Fluorescent lamp, tube
  • Commercial Illuminate and displays: Advertising words, light box
  • Decorative Lighting: Light Strip
  • Other illuminations
  • Led back lighting





0.06W 3V 3528 SMD LED Chip 520nm-525nm Green LED Chip Wide Viewing Angle 3

0.06W 3V 3528 SMD LED Chip 520nm-525nm Green LED Chip Wide Viewing Angle 4







0.06W 3V 3528 SMD LED Chip 520nm-525nm Green LED Chip Wide Viewing Angle 5
