1313 Bi-Color COB LED Chip 900lm-1100lm 2700K-5400K 12*2W 20-24V Ra 90

Basic Information
Place of Origin: China
Brand Name: HuanYu Dream
Certification: RoHS
Model Number: HY-1310D2857-7S3P-24-F3
Minimum Order Quantity: 1piece
Price: Negotiated
Packaging Details: 49pcs/Tray
Delivery Time: 10-15 Work Days
Payment Terms: T/T, Paypal,Ali Pay
Supply Ability: 30000 units per day
Detail Information
Product Name: 1313 Bi-Color COB Led Chip Working Time: 50000 Hours
Power: 12W+12W Series: CW: 7S1P WW: 7S2P
Warranty: 3 Years Lifespan: 50000 Hours
Luminous Intensity: 900-1100 LM Color Temperature: 2700K/5400K
High Light:

COB LED Chip 900lm

,

1313 Bi-Color COB LED Chip

,

COB LED Chip 2700K


Product Description

1313 Bi-Color COB Led Chip 900-1100lm 2700-5400K 12*2W 20-24V Ra 90



1313 Bi-Color COB Led Chip Introduction



* Dimension 13.50mm×13.50mm×1.5mm

* CRI: 90

* Wide viewing angle : 120°

* RoHS compliant

* Sulphation corrosion resistance

* Manual Soldering

* The White LED which was fabricated using a blue chip and phosphor



1313 Bi-Color COB LED Chip 900lm-1100lm 2700K-5400K 12*2W 20-24V Ra 90 0











1313 Bi-Color COB Led Chip Details



1313 Bi-Color COB LED Chip 900lm-1100lm 2700K-5400K 12*2W 20-24V Ra 90 1





Electrical - Optical Characteristics at Ta=25℃

Type

Symbol

Test condition

Value

Unit

      Min. Typ. Max.
Forward Voltage VF IF=600mA 18 20 22 V
2700K-2900K φ IF=600mA 900 -- 1100 Lm
5400K-5800K φ IF=600mA 1000 -- 1200 Lm
Viewing Angle 2θ1/2 IF=600mA   120   Deg
Color Rendering Index CRI IF=600mA 90 -- 93 --
Thermal resistance Rth(j-s) IF=600mA -- -- 0.67 ℃/W







Absolute Maximum Ratings at Ta=25



Parameter

Symbol

Rating

Units

Power Dissipation

Pd

12W*2

W

Forward Current

IF

600

mA

Peak Forward Current

IFP

700

mA

Junction temperature

Tj

115

Solder temperature

Ts

350

Operating Temperature

Topr

-40 ~ + 85

Storage Temperature

Tstg

-40 ~ + 100











Optica Characteristic curve

1313 Bi-Color COB LED Chip 900lm-1100lm 2700K-5400K 12*2W 20-24V Ra 90 2









1313 Bi-color COB Led Chip Package Dimension



1313 Bi-Color COB LED Chip 900lm-1100lm 2700K-5400K 12*2W 20-24V Ra 90 3







1313 Bi-Color COB LED Chip 900lm-1100lm 2700K-5400K 12*2W 20-24V Ra 90 4













1313 Bi-Color COB Led Chip Applications

1313 Bi-Color COB LED Chip 900lm-1100lm 2700K-5400K 12*2W 20-24V Ra 90 5



1313 Bi-Color COB LED Chip 900lm-1100lm 2700K-5400K 12*2W 20-24V Ra 90 6




1313 Bi-Color COB LED Chip 900lm-1100lm 2700K-5400K 12*2W 20-24V Ra 90 7















Production Process

1313 Bi-Color COB LED Chip 900lm-1100lm 2700K-5400K 12*2W 20-24V Ra 90 8

1313 Bi-Color COB LED Chip 900lm-1100lm 2700K-5400K 12*2W 20-24V Ra 90 9









FAQ
Q1: Are you a factory or a trade company?
We are the manufacturer specialize in smd and cob led chips since 2013.


Q2: Can I get some samples for tests?
 Yes, we can offer free samples, so you can have an intuitive understanding about our LED quality and performance. But our clients should pay for the shipping freight themselves.



Q3: What about the lead time?
 Generally, it will take 3-5 working days for sample and 7-25 working days for mass order.



Q4: Do you accept customized products?
Yes, we can offer OEM and ODM service as per your request. Please kindly leave us messages about your requirements, our sales engineer will check the details as soon as possible.



Q5: How many years of warranty of products you offer? And how do you deal with the LED working issues?
 We offer 3-year warranty by default, and longer warranty can be negotiated. If there is any problem with the product during the warranty, please feel free to contact us.
